Audio Technica AT875R

169.00 USD

Audio Technica’s shortest shotgun microphone, mounts conveniently on a DV camcorder without adding noticeable weight, and is ideal for use with compact digital cameras.

Quantity:

Description

Audio Technica’s AT875R is designed for video production and broadcast (ENG/EFP) audio acquisition. Audio Technica’s shortest shotgun microphone, mounts conveniently on a DV camcorder without adding noticeable weight, and is ideal for use with compact digital cameras. The AT875R’s small profile is one of the distinguishing things about it, considering that trying to place some of the industries longer shotgun microphones on small DV Cams is challenging at best.

This high-performance microphone offers a narrow acceptance angle of line + gradient design. It also features smooth, natural-sounding on-axis audio quality and excellent off-axis rejection of sound arriving from the sides and rear of mic.

Protective carrying pouch, stand clip (with 5/8″ to 3/8″ adapter) and windscreen are included.

Features

  • Designed for video production and broadcast (ENG/EFP) audio acquisition
  • Extremely short length (under 7″) ideal for use with compact digital camera
  • Provides the narrow acceptance angle desirable for long-distance sound pickup
  • Excellent sound rejection from the sides and rear of mic
  • Tailored response minimizes camera and handling noise
  • Operates on phantom power only
Element Fixed-charge back plate, permanently polarized condenser
Polar Pattern: Line + gradient
Frequency Response: 90-20,000Hz
Open Circuit Sensitivity: -30dB(31.6 mV) re 1V at 1Pa
Impedance: 100ohms
Maximum Input Sound Level: 127dB SPL, 1kHz at 1% T.H.D.
Dynamic Range (typical): 107dB, 1 kHz at Max SPL
Signal-to-Noise Ratio: 74dB,1 kHz at 1Pa
Phantom Power Requirements: 11-52V DC, 2mA typical
Weight: 80g(2.8oz)
Dimensions: 175.0mm(6.89") long, 21.0mm(.83") diameter
Output Connector: Integral 3-pin XLRM-type
Accessories Furnished: AT8405a stand clamp for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter;windscreen;soft protective pouch
Audio-Technica Case Style: SG4

Frequency Response

AT875 Frequency Response

Polar Pattern

AT875 Polar Pattern

Read a review of the AT875R

Download the AT875R One Sheet (111KB PDF)
