Shure ADTD Axient Digital PSM Dual Wireless Transmitter — Dual-radio digital wireless stereo transmitter for the Shure Axient Digital PSM system. The ADTD reimagines in-ear monitoring wireless transmission with its groundbreaking performance, ensuring faultless results in the most challenging RF environments. Features include scalable channel count (available in planned firmware update, date TBD), Multichannel Wideband RF, and Spatial Diversity Transmission, along with the ShowLink® remote control, networkable monitoring with Wireless Workbench®, analog and digital (AES3, AES67, Dante) inputs, and internal antenna combining, bringing a new level of management and flexibility to your entire in-ear monitor workflow. Axient Digital PSM ADTD is compatible with the Axient Digital PSM ADXR bodypack receiver.

Available with standard AC powering or DC. Available frequency bands: G57 (470-608 MHz); K54 (606-608, 614-616, 652-663 MHz); and X55 (941-960 MHz)

Features

• Two-radio, digital wireless stereo transmitter for Shure Axient Digital PSM in-ear monitoring system
• Powered by Shure WMAS innovation*, ADTQ delivers flexible, pioneering spectral efficiency and access to scalable channel count**
• Patented Spatial Diversity transmission defends against multipath interference
• Four different transmission modes to choose from:
  • Multichannel Wideband – Shure WMAS innovation* powers the ADTQ to deliver up to four stereo audio channels, not just one, with each ADTQ radio
  • Narrowband – Access more RF output power for greater range with this traditional option
  • Analog FM – Achieve virtually zero latency performance with updated hybrid technology
  • Axient Digital Standard** – Turn the ADTQ into an AD series Axient Digital transmitter and send high-quality, long-distance wireless audio to any Axient Digital wireless receiver
• Wide tuning range to cover more cities, festivals, and events on tour
• Real-time remote control of all ADXR bodypack wireless receiver parameters from the monitor mix position and elsewhere with exclusive ShowLink technology
• Encrypted RF signal ensures every transmission is secure
• Five-segment Channel Quality meter displays RF signal-to-noise
• Large, 6.6-inch front panel color display
• Networked control with Shure Wireless Workbench for extended and enhanced RF monitor and management
• Optional internal antenna combining reduces or eliminates external combiners
• 4 x switchable combo connectors for analog or AES3 digital options
• 4 x Ethernet ports for network control and Dante/AES67 digital input options
• 2 x coaxial RF antenna output connectors
• 1 x 3.5mm front-panel headphone connector with adjustable volume
• Locking AC power connection that cascades to additional components
• DC module version available to support redundant power

*  The availability of WMAS features is subject to regional regulations and may vary accordingly.
** Available in planned firmware update, date TBD

Axient Digital PSM Overview

Powered by Shure WMAS innovation, the Axient Digital PSM next-generation personal monitoring system delivers unmatched sound quality, redefining in-ear monitoring and pushing the boundaries of what’s possible. The Shure Axient Digital PSM system provides consistent, reliable in-ear monitoring in the most demanding environments, such as large-scale concerts and complex productions. Every detail of your mix reaches the performer with incredible clarity and precision. With real-time, low-latency monitoring, Axient Digital PSM gives audio engineers the freedom to make precise adjustments in the moment. Its flexible, expandable capabilities keep you focused on delivering the perfect mix, with zero compromise.

Works effortlessly with other Shure products, allowing you to build a powerful, integrated system that elevates every aspect of your production. No matter the number of performers or the level of complexity, Axient Digital PSM adapts effortlessly, ensuring everything sounds flawless.
